Deye 18Kw Single Phase LV Hybrid Inverter 48V

Intelligent Solar Energy Management

The Deye 18kW Hybrid Inverter provides a powerful and versatile energy solution for properties requiring greater energy independence, efficient solar utilisation and dependable backup power.

Designed for demanding energy applications, the inverter intelligently manages electricity from solar panels, battery storage and the utility grid to maintain an efficient and reliable power supply.

Reliable Backup and Energy Security

The system helps protect essential electrical loads during grid interruptions while optimising the use of available stored energy. This makes it a practical solution for properties with high electricity demands and businesses seeking to minimise operational disruptions.

Flexible System Integration

Its versatile energy management capabilities allow integration into new solar installations or the expansion of existing energy systems.

The inverter is suitable for installations requiring adaptable energy storage configurations and future system expansion.

Smart Energy Optimisation

Advanced energy management settings allow users to control electricity usage according to their consumption patterns, helping to maximise solar self-consumption and reduce unnecessary grid electricity purchases.

Ideal Applications

• Large residential properties and estates
• Commercial offices and business premises
• Farms and agricultural operations
• Guesthouses and hospitality facilities
• Workshops and small industrial facilities
• Properties requiring dependable energy backup

Technical Specifications

• Model Number: SUN-16K-SGLP1-EU-AM3-P
• Battery Type: Lead-acid or Lithium-ion
• Battery Voltage Range: 40-60V
• Max. Charging Current: 350A
• Max. Discharging Current: 350A
• Charging Strategy for Li-ion Battery: Self-adaption to BMS
• Number of Battery Input: 2
• Max. PV Access Power: 36000W
• Max. PV Input Voltage: 500V
• Start-up Voltage: 125V
• MPPT Voltage Range: 150-370V
• Rated PV Input Voltage: 370V
• Max. Operating PV Input Current: 36+36+36A
• Max. Input Short-Circuit Current: 54+54+54A
• No. of MPP Trackers/No. of Strings MPP Tracker: 3/2+2+2
• Rated AC Input/Output Active Power: 18000W
• Max. AC Input/Output Apparent Power: 19800VA
• Grid Connection Form: L+N+PE
• Max. Efficiency: 97.6%
• Euro Efficiency: 96.5%
• MPPT Efficiency: 99%
• Communication Interface: RS485/RS232/CAN
• Monitor Mode: GPRS/WIFI/Bluetooth/4G/LAN(optional)
• Operating Temperature Range: -40 to +60℃, >45℃ Derating
• Permissible Ambient Humidity: 0-100%
• Permissible Altitude: 3000m
• Noise: <55dB
• Ingress Protection(IP) Rating: IP 65
• Inverter Topology: Non-Isolated
• Over Voltage Category: OVC II(DC), OVC III(AC
• Type of Cooling: Intelligent Air Cooling
• Warranty: 5 Years/10 Years
• Grid Regulation: IEC 61727, IEC 62116, AS 4777.2, NRS 097
• Safety / EMC Standard: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
